Features:
Low-speed ,Anti-shake, ultra-low noise
Fault phase protection, overcurrent protection
Drive overheat protection
Multiple subdivision options
(Can be customized according to customer requirements)
Optically isolated signal input
Input pulse frequency 0-200kHz
Automatic low-power operation at rest
Single power input, voltage range:20V-120V DC
Electrical Specifications (Tj = 25oC/77oF)
|
Type
|
H2MD
|
|
Min
|
Typical
|
Max
|
Unit
|
|
Output current
|
1.8
|
-
|
6.0
|
A
|
|
Supply voltage
|
+20
|
+
|
+120
|
VDC
|
|
Logic signal current
|
7
|
10
|
16
|
mA
|
|
Pulse input frequency
|
0
|
-
|
300
|
kHz
|
|
Isolation resistance
|
500
|
|
|
Moh
|
Typical Connection:
Size:mm(inch)
