11HY3401B

11HY3401B

2 phase,1.8 degree,nema 11,size 28x28x33mm,rated current/phase 0.6A,holding torque 6Ncm (8.5oz.in),single shaft with flat, 4 wires,

Price$20.00

Number 20 In Stock

Price Break
Qty Price($)
1-5 20.00
6-10 16.00
11-20 13.00
Contact us for qty 21 & up
Services:
  • quality assurance
  • Service assurance
  • customer service
  • Description
  • Specifications
  • Customize
  • Downloads
  • Ask a Question

 Model: 11HY3401B

Phase:2

Step Angle: 1.8 deg

Holding Torque:6Ncm (8.5oz.in)

Rated Current/phase: 0.6A

Voltage: 3.3V

Inductance: 3.2mH ± 20%(1KHz)

Phase Resistance: 5.5ohms



Frame Size: 28 x 28mm

Body Length: 33mm

Shaft Diameter: Φ5mm  D-cut

Shaft Length: 20mm

Number of Leads: 4

Lead Length: 300mm


Tags: nema 11, 11HY3401B, bipolar, 1.8deg, 0.6A,3.3V,6Ncm (8.5oz.in),28x28x33mm, 4 ,wires,
